Flat die-cutting machine (WQM-320G)

A.CHARACTERISTIC This die-cutting machine adopts accurate flatten die-cutting system, material towing controlled by computer, web-guiding by three photoelectric eyes. Die cutting, waste rewinding and finished-material rewinding are finished in one process. It is suitable for die cutting of adhesive paper, Dacron label and laser hologram mark, This is the ideal association equipment for the flexo printing machine, silk screen printing machine, gravure printing machine and hologram mark printing machine, and it's the most efficient machine for printing house. B.MAIN TECHNICAL SPECIFICATION Model 320G model Cutting speed 20-170 t/min Max. unwinding diameter 500mm Max. web width 320 mm Max. die-cutting width 300 mm Max. die-cutting length 300 mm Orientation accuracy ±0.1mm Total power 3.5KW Power voltage 220V±10% Machine weight 1700kg Overall dimensions 2.75mX1.21mX1.76 m
