Slitting machine with rotary die-cutting station

DK-320Gslitting machine with rotary die-cutting function is a new product , it equipped with high accurate rotary die-cutting system . This machine is suitable for blank adhesive labels . Die-cutting , Laminating(option), Slitting can be finished in one process . It has the function of automatic meter counting , automatic stop, web guiding by photocell . The machine has the characteristic of compact structure, fast speed , high efficiency , easy operation , accurate slitting and steady running ect. Main Technical Specification : Slitting speed : 75m/min Die-cutting speed : 60m/min Die-cutting repeat length: 177-476mm Max web width:320mm Max unwinding diameter:500mm Max rewinding diameter:480mm Overall dimension: 1.6(L) X 0.9(W) X 1.3(H) (M) Machine weight: About 600kgs
