ZBS-320 Label printing machine

ZBS-320 Label printing machinery A.CHARACTERISTIC 1, Adopt the ceramic anilox cylinder to transfer the ink. 2, Unwinding and rewinding are controlled by magnetic power brake, clutch, (Or controlled by auto tension controller of Mitsubishi of Japan). 3, Each printing unit adopts 3600 plate-adjustment. 4, IR dryer for each printing unit.(UV dryer is for option) 5, This machine has die-cutting station, and it can make printing and die cutting finished in one process. 6, The ink rollers will be separated from the printing roller, and keep running when the machine stopped. 7, The main motor adopts frequency conversion stepless timing motor. 8, The machine can finish material-feeding, printing, lighting, drying, laminating, die-cutting and rewinding in a lump.It is an ideal machine for printing note and top-grade adhesive label. B.MAIN TECHNICAL SPECIFICATION Printing speed 50m/min Printing color 5colour Max. width of paper 320mm Max .printing width 310mm Max. unwinding diameter 600mm Max. rewinding diameter 600mm Printing length 175-320mm Precision of chromatography ±0.1mm Dimensions 2000x 1100 x 3100 mm Machine weight 2800KGS Standard Equipment: 3 x full sets of printing cylinders 1 x printing plate mounter. 1 x Toolbox. Printing Repeat Length: Standard : Z56 - Z112 Option 1 : Z65 - Z145 Option 2 : Z75 - Z170 Material Substrate: 10 Micron Film To 400 Micron Board Unsupported Film Aluminium Foil Tissue paper Self adhesive paper Vinyls/PVC Carton weight board Options: • Free standing unwind with roll lifter, roll diameter max 900mm. • Corona Treater. • UV Dryer • Additional printing units. • Cold foiling. • Video web inspection
